If you think that you want to use one of these Beamline dedicated CCRs on your experiment or if you have any question about any of our equipment please contact the sample environment team, or the respective instrument scientist. The CCR Parameters PDF contains additional information about some of the CCRs.

CCR NUMBER	Beamline	Head type	Temperature Range	Tail Type	Beam Height
CCR 10	LOQ	LEYBOLD 1040	10K-300K	AL	NA
CCR 20	ENGIN-X	LEYBOLD 1245	10K-300K	NA	NA
CCR 21	SXD	LEYBOLD 1245	10K-300K	VAN	300mm
CCR 22	ENGIN-X	LEYBOLD 1245	10K-300K	NA	NA
CCR 23	POOL	LEYBOLD 1245	10K-800K	AL/VAN	300mm
CCR 24	SXD	LEYBOLD 1245	10K-300K	VAN	300mm
CCR 26	MAPS	LEYBOLD 4K	4K-300K	AL	300mm
CCR 27	SXD	LEYBOLD 1245	10K-300K	VAN	300mm
CCR 28	PRISMA	LEYBOLD 1245	10K-300K	AL	337mm
CCR 30	TOSCA	LEYBOLD 120	10K-300K	AL	NA
CCR 46	VESUVIO	LEYBOLD 1245	10K-300K	AL	300mm
CCR 65	TOSCA	SUMITOMO 415	4K-300K	AL	NA
CCR 68	TOSCA	SUMITOMO 415	4K-300K	AL	NA
CCR 43	ROTAX	LEYBOLD 4K	4K-300K	AL/VAN	300mm
CCR 69	HIFI	SUMITOMO 415	4K-300K	AL	NA
CCR 72	EMU	SUMITOMO 415	4K-700K	AL	NA
